Model HUYAir Bio2-1200 A1 Prime | Biosafety Cabinet Class II, Type A1

  • Integrated microprocessor controller with 4.3-inch touch screen
  • Standard compliance: NSF 49, EN 12469, ISO 14644.
  • Size standard: 1200mm.
  • Warranty: 3 years.

FEATURES

  • Biosafety cabinet class II, type A2 – HUYAir Bio2 A1 Prime ensures protection for the operator, sample, and the environment.
  • Structure: 2 layers, both the interior made of SUS 304 stainless steel and exterior made of electro-galvanized steel resistant to chemicals and microbe
  • UV-resistant tempered sliding sash with counterweight.
  • DC motor and EBMpapst fan from Germany ensures energy savings.
  • Work zone: ISO class 4
  • HEPA (H14) or ULPA (U15) filters from Camfil (Sweden) or AAF (USA) with 99.999% (H14) or 99.9999% (U15) filtration at 0.3 µm/0.1 µm.
  • Integrated microprocessor controller with touch screen displays real wind speed, time settings, UV, door opening warning and wind speed according to settings, and can be adjusted directly on the screen about fan speed.
  • The cabinet angle is 10° for easy operation
  • There are access ports for accessories such as valve of air, water, gas, and head for online particle counting samplers.
Model HUYAir Bio2-1200 A1 Prime
Controller Microcessor with 4.3-inch screen
Downflow velocity 0,35 m/s
Inflow velocity 0,38 m/s
Light >750 lux
Noise <65 dB
Maximum sash opening height 541.7mm
Motor DC
External dimensions (W x D x H) 1380 x 816 x 1520 mm
Internal dimensions (W x D x H) 1260 x 610 x 648 mm
External dimensions including cabinet legs (W x D x H) 1380 x 816 x 2240 mm
Voltage – Frequenciens 200 – 240V, 50/60 Hz
Warranty 3 years
Support Stand Support Stand with caster wheels | Height 800mm for model HUYAir Bio2
  Support Stand with cabinets | Height 800mm for model HUYAir Bio2
Power accessories Power outlet
Vans accessories Gas vans | Gas (such as N2) | Vacuum vans
  Water vans
Filter accessories ULPA filter (H15)
  • The surrounding air is drawn in through the front grille and the side walls, creating an inward airflow.
  • The incoming airflow is divided into two portions: 30% of the airflow will be exhausted outside through the exhaust filter, and 70% of the airflow will be evenly distributed over the surface of the HEPA filter, creating a downward vertical airflow.



BROCHURE_HUYAir Bio2 A1 Prime | Biosafety Cabinet Class II, Type A1
