FEATURES
- Ductless Fume Hood with Carbon Filter – HUYAir DFH Elite is designed with a specialized carbon filtration system to protect users when working with hazardous chemicals and volatile solvents.
- Structure: 2 layers with interior made of PP plastic; exterior made of electrogalvanized steel coating by powder resistant chemical, UV, and bacteria.
- UV-resistant tempered glass door, sliding with counterweight.
- EBMpapst motor from Germany ensures energy savings.
- Work zone: ISO class 5
- Modified Carbon filter for chemical vapor adsorption.
- Microprocessor-controlled touchscreen shows real-time airflow, time, UV, with on-screen calibration for airflow and fan.
- The cabinet angle is 7° for easy operation
- There are access ports for accessories such as valve of air, water, gas, and head for online particle counting samplers.
Model | HUYAir DFH – 1800 Elite |
Controller | Microcessor with 8.88-inch screen |
Inflow velocity | 0.3 – 0,5 m/s |
Light | >750 lux |
Noise | <65 dB |
Maximum sash opening height | 710 mm |
Motor | DC |
External dimensions (W x D x H) | 1800 x 945 x 1500 mm |
Internal dimensions (W x D x H) | 1600 x 695 x 1070 mm |
External dimensions including cabinet legs (W x D x H) | 1800 x 945 x 2400 mm |
Cabinet weight | 280 kg |
Power | 572W |
Voltage – Frequenciens | 200 – 240V, 50/60 Hz |
Warranty | 3 years |
Support Stand | Support Stand with caster wheels | Height 800mm for model HUYAir FH | |
Support Stand with cabinets | Height 800mm for model HUYAir Bio2-Eco | ||
Power accessories | Power outlet | |
Vans accessories | Gas vans | Gas (such as N2) | Vacuum vans | |
Water vans | ||
Sink accessories | Mini sink | |
Phụ kiện lọc carbon GVS – Anh | 1. GP – General organic compound removal (i.e solvents, odours, organic acids etc) | |
2. CYN – Removal of compounds containing Cyanide (and general organics) | ||
3. AMM – Removal of compounds containing Ammonia & Amine (and general organics) | ||
4. FOR – Removal of Formaldehyde (and general organics) | ||
5. ACI – Removal of inorganic acids and general organics (including Sulphur compounds) | ||
6. ACR- Removal of Alkali compounds (and general organics) | ||
7. ETH – Removal of compounds containing Ether (and general organics) |
![]() |
|
